Synthesis NYC 500 Valve Monobloc Power Amplifier
The Synthesis NYC 500 Valve Monobloc Power Amplifier offers high-end audio performance with a robust output of 500 watts per channel. Designed with audiophiles in mind, it features vacuum tube technology that delivers a warm, dynamic sound signature. This amplifier's monobloc design ensures dedicated power to each channel, minimising distortion and improving overall sound clarity. Ideal for larger audio setups, the NYC 500 supports a wide range of speaker types, making it a versatile choice for high-fidelity systems. Its premium construction and sleek aesthetic also enhance its appeal for both sound quality and design-conscious users.
Specifications
Synthesis NYC 500 Valve Monobloc Power Amplifier
| Specification | Value |
|---|---|
| Power stage (1 ch.) |
8 X KT120 |
| Input stage (1 ch.) |
2 X 12AU7/ECC82 |
| Driver stage (1 ch.) |
2 X 12BH7 |
| Input impedance |
100KOhm |
| Input sensitivity |
2.4V RMS unbalanced input (RCA), 4.8V RMS balanced input (XLR) |
| Output tap |
4/8 Ohm bi-wiring connection |
| Configuration |
Push-Pull Ultra linear 20% tap |
| Power output |
500W RMS @ 4/8 Ohm (THD 1%), 550W RMS @ 4/8 Ohm (THD 3%) |
| Frequency response |
20Hz to 20KHz ± 0dB, 2Hz to 70KHz - 3dB |
| Distortion |
1% @ 1KHz (Max Power) |
| S/n ratio |
>90dB “A” weighted |
| Inputs |
Line unbalanced: 1 (RCA) Line balanced: 1 (XLR) |
| Outputs |
Pre out (variable level) |
| Bias setting |
Manual adjustment by LED indicator, Independent for each power tube |
| Dimensions (w,d,h) |
470x620x260mm |
| Weight |
60Kg |
| Line power |
117, 230, 245 Vac 50/60 Hz (see rear label) |
| Fuse |
See rear label |
| Power consumption |
1500W Max |
| Remote control |
Body: Anodized black aluminium Transmission type: Infrared Protocol: RC5 Functions: Volume, mute Batteries: 2 x CR2032 Weight: 200g |
Synthesis NYC 500 Valve Monobloc Power Amplifier
Sale price$40,000.00 AUD
