Furutech FP-705M(R) & FP-706F(R) Performance 4-Pin XLR Connector (each)

Brand: Furutech

Furutech FP-705M(R) & FP-706F(R) Performance 4-Pin XLR Connector (each)

$50.00 AUD

Furutech FP-705M(R) & FP-706F(R) 4 Pin Balanced XLR Connectors are high-end audio terminations designed for precise, low-loss signal transfer in balanced headphone cables and professional audio systems. Featuring rhodium-plated α (Alpha) copper alloy conductors, PBT/fibreglass insulation, and non-magnetic zinc alloy housings, these solder-type connectors offer exceptional conductivity, shielding, and durability. Compact yet robust, they support cable diameters up to 9mm and ensure a secure, high-fidelity connection in demanding environments.

Connector type: FP-705M (R)

FP-705M (R) FP-706F (R)

Quantity:

✓ Australian Retailer
✓ Full Australian Warranty
✓ Fast Australia-Wide Shipping
✓ Local Expert Support

Specifications

Furutech FP-705M(R) & FP-706F(R) Performance 4-Pin XLR Connector (each)

Specification	Value
Main conductor	Rhodium-plated α (Alpha) Copper alloy conductor
Insulation	PBT and fibreglass Resin
Housing	Nonmagnetic Zinc/Al alloy and Copper alloy (End shell)
Connections	Soldered
Cable diameter max	9mm
Fp-705m dimensions	18.8mm ± 0.1mm diameter x 63.2mm ± 0.1mm overall length
Fp-706f dimensions	19.5mm ± 0.1mm diameter x 64.2mm ± 0.1mm overall length

Product Details

Furutech FP-705M(R) & FP-706F(R) Deliver Precision Audio Transmission

Furutech FP-705M(R) & FP-706F(R) 4 Pin Balanced XLR Connectors are high-performance, audiophile-grade terminations engineered to deliver uncompromised signal integrity in demanding balanced audio systems. These premium connectors are specifically designed for enthusiasts, professional technicians, and manufacturers seeking exceptional build quality and optimised conductivity in balanced interconnects, such as those used in high-end headphones, DACs, preamps, and studio gear.

FP-705M(R) & FP-706F(R) Feature Rhodium-Plated Alpha Copper for Signal Purity

Furutech FP-705M(R) & FP-706F(R) XLR connectors are precision-machined using rhodium-plated α (Alpha) copper alloy contacts, ensuring exceptionally low resistance and enhanced durability. Rhodium plating provides a stable, corrosion-resistant surface that maintains reliable signal transfer over time, ideal for applications where sonic neutrality and mechanical longevity are paramount. The proprietary α (Alpha) process, which combines cryogenic treatment and demagnetisation, significantly improves conductivity and minimises magnetic interference, ensuring signal fidelity remains intact even under dynamic load.

PBT Fibreglass Insulation Enhances Electrical Isolation

Each Furutech FP-705M & FP-706F connector incorporates a carefully selected PBT and fibreglass composite insulator, designed to withstand high soldering temperatures while providing superior dielectric properties. This material blend reduces parasitic capacitance and mechanical resonance within the connector body, preserving the original signal waveform during transmission. The combination of this insulating medium with the high-quality conductor alloy contributes to a clean, articulate sound profile—especially noticeable in the midrange articulation and high-frequency extension when used in balanced headphone cables or line-level interconnects.

Rugged Zinc Alloy Housings Offer Shielded Durability

Furutech’s FP Series 4-pin XLR connectors are encased in non-magnetic zinc and copper alloy housings with a black painted finish that resists EMI and RFI intrusion. This shielding is essential in professional audio environments where signal chain integrity must be maintained amidst multiple sources of electromagnetic interference. The precisely toleranced end-shell threads and shell alignment contribute to a solid mechanical connection, reducing long-term wear and ensuring minimal microphonics during handling or cable movement.

Solder-Type Terminals Ensure Secure Custom Termination

The FP-705M(R) male and FP-706F(R) female connectors are designed for soldered connections, offering a secure and lasting joint that eliminates the signal degradation common in inferior mechanical contact systems. The solder lugs accommodate a wide range of cable geometries and are specified to support cable diameters up to 9mm, making these connectors ideal for both compact audiophile-grade builds and thicker professional cabling systems.

Compact Dimensions Support Space-Saving Applications

Furutech’s FP-705M and FP-706F 4-pin connectors maintain a space-saving form factor, with diameters under 20mm and lengths just over 63mm, making them a perfect match for tight builds or portable balanced headphone systems. Whether integrated into a custom interconnect for high-end planar magnetic headphones or used in studio-grade balanced patch cables, these connectors strike a fine balance between robust construction and installation flexibility.

FP-705M(R) & FP-706F(R) Provide High-Fidelity Balanced Connectivity

The Furutech FP Series XLR connectors, including the FP-705M(R) male and FP-706F(R) female 4-pin variants, are designed for balanced signal transfer in audiophile, broadcast, and recording studio applications. Their low impedance design, premium metallurgy, and shielded structure allow them to be used in noise-sensitive setups without compromising performance. These connectors are widely adopted in high-end headphone cables, such as Audeze, Focal Utopia, and HiFiMAN balanced rigs, where low resistance and precise pin alignment are essential for safe and accurate signal delivery.

Furutech FP-705M(R) & FP-706F(R) connectors are a trusted choice for those seeking a professional-grade solution that merges acoustic transparency with mechanical resilience.
