Lehmann Audio Decade Jubilee Phono Preamplifier
Lehmannaudio Decade Jubilee Phono Preamplifier is a premium dual-mono MM/MC stage designed for discerning vinyl enthusiasts. Featuring the ultra-precise passive RIAA network from the Silver Cube, a powerful Class A output stage, and a fully external PWX II LC power supply, it delivers exceptional clarity, transient speed, and immersive soundstage performance. Front-panel controls offer easy access to gain, impedance, and bass filter settings, ensuring compatibility with a wide range of cartridges. Housed in a low-resonance aluminium chassis and available in Aluminium Black, Aluminium Silver, and Chrome finishes, the Decade Jubilee is crafted for both sonic purity and visual elegance.
To secure a unit, please enquire directly regarding current availability, as lead times may vary.
Specifications
Lehmann Audio Decade Jubilee Phono Preamplifier
| Specification | Value |
|---|---|
| Model |
Decade Jubilee |
| Sensitivity for output level |
775 mV / 0 dB (with activated high gain switch) |
| Gain 1 khz mm |
46 dB |
| Gain 1 khz mc |
66 dB |
| Maximum input level 1 khz mm |
45 mV |
| Maximum input level 1 khz mc |
4.5 mV |
| Signal to noise ratio mm |
78 dB |
| Signal to noise ratio mc |
69 dB |
| Input sensitivity mm |
3.8 mV / 1 kHz |
| Input sensitivity mc |
0.38 mV / 1 kHz |
| Gain options |
36 dB, 46 dB, 56 dB, 66 dB |
| Channel separation |
> 80 dB at 10 kHz |
| Input impedance |
47 kohms, 1 kohm, 100 ohms |
| Custom load inputs |
1 x custom load |
| Output impedance |
5 ohms |
| Input capacitance |
47 pF to 1,370 pF |
| Channel mismatch |
typ. max 0.5 dB |
| Bass filter |
50 Hz, 6 dB/oct. |
| Power consumption |
app. 13 VA |
| Outer dimensions audio section |
110 mm x 280 mm x 50 mm |
| Outer dimensions pwx ii lc power supply |
110 mm x 280 mm x 50 mm |
| Weight audio section |
0.87 kg |
| Weight pwx ii lc power supply |
1.56 kg |
