Brand: Lehmann Audio
Lehmann Audio Linear D MkII Headphone Amplifier Streaming Preamplifier
Lehmannaudio Linear D MKII is a premium headphone amplifier and streaming preamplifier that delivers high-resolution sound through a discrete class A output stage and a state-of-the-art ESS Sabre DAC. Designed for audiophiles, it features automatic digital input selection, adjustable gain settings, and precision analogue filtering for crystal-clear playback. With dual headphone outputs, a pre-out for active speakers, and vibration-isolating 3S Device Feet, the Linear D MKII offers pristine sound, elegant control, and versatile connectivity in a compact, German-engineered chassis.
To secure a unit, please enquire directly regarding current availability, as lead times may vary.
Specifications
Lehmann Audio Linear D MkII Headphone Amplifier Streaming Preamplifier
Specification | Value |
---|---|
Product |
Linear D |
Input impedance |
47 kOhms |
Maximum gain |
0 dB, 10 dB, 18 dB, 20 dB selectable via DIP switches |
Frequency response |
10 Hz (-0.3 dB) to 35 kHz (-1 dB) |
Signal to noise ratio |
> 100 dB at gain 0 dB |
Thd |
< 0.001 % at 6 mW/300 Ohms |
Channel separation |
> 80 dB at 10 kHz |
Output power |
400 mW/60 Ohms, 200 mW/300 Ohms |
Output impedance |
pre-out 50 Ohms, phones out 5 Ohms |
Connectors audio |
Neutrik headphone jacks with gold plated contacts, 1 x pre-out, 2 x phones out, gold plated RCA sockets with teflon insulation |
Power consumption |
15 W through internal, regulated power supply |
Special feature analogue section |
analogue board in Low-Z Copper, vibration-absorbing 3S Device Feet |
Outer dimensions |
110 mm x 280 mm x 44 mm (4.3 x 11 x 2 in.) |
Weight |
1.5 kg (3.3 lbs.) net |
Digital inputs |
1 x TOSLINK (automatically prioritised), 1 x RCA 75 ohms |
Sampling rates |
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 192 kHz |
Resolution |
24 bits |
Chipset |
ESS Sabre K2M |
Analogue filter |
Silver Mica capacitators |
Max. output level dac |
1.8 V eff. |
Special feature dac |
The analogue input is automatically activated, when no digital signal is recognised |
Product Details

Lehmann Audio Linear D MkII Headphone Amplifier Streaming Preamplifier
Sale price$4,080.00 AUD
