Lehmann Audio Linear SE II Headphone Amplifier Preamplifier
Lehmannaudio Linear SE is a high-end headphone amplifier and preamplifier built for audiophiles who demand uncompromised sound quality. Its Low-Z Copper analogue board, discrete Class A output stage, and Mundorf capacitors deliver a transparent, natural listening experience across all dynamic headphones. With selectable gain up to 20 dB, dual gold-plated Neutrik outputs, and preamp functionality, it offers both flexibility and precision. The elegant aluminium housing is customisable with various finishes, LED colours, and control elements. Optional USB and TOSLINK DAC modules support high-resolution playback, making the Linear SE ideal for both analogue and digital audio setups.
To secure a unit, please enquire directly regarding current availability, as lead times may vary.
Specifications
Lehmann Audio Linear SE II Headphone Amplifier Preamplifier
Specification | Value |
---|---|
Model |
Linear SE |
Input impedance |
47 kohms |
Maximum gain |
0 dB, 10 dB, 18 dB, 20 dB selectable via DIP switches |
Frequency response |
10 Hz (-0.3 dB) to 35 kHz (-1 dB) |
Signal to noise ratio |
> 100 dB at gain 0 dB |
Thd |
< 0.001 % at 6 mW/300 Ohms |
Channel separation |
> 70 dB at 10 kHz |
Output power 60 ohms |
400 mW |
Output power 300 ohms |
200 mW |
Output impedance pre-out |
60 Ohms |
Output impedance phones out |
5 Ohms |
Connectors audio |
Neutrik headphone jacks with gold plated contacts, 1 x pre-out, 2 x phones out, gold plated RCA sockets with teflon insulation |
Power consumption |
10 W |
Outer dimensions |
120 mm x 296 mm x 59 mm |
Weight |
2.2 kg netto |
Digital options usb-dac 384/32 prioritization |
I: USB input, II: line input analogue |
Digital options toslink/spdif dac 192/24 prioritization |
I: TOSLINK input, II: RCA input digital, III: line input analogue |
