Ortofon 2MR Black LVB 250 Cartridge

Why move up from the 2M Black to the 2MR Black LVB 250?

The 2MR Black LVB 250 is built on the 2M Black platform but changes the cantilever, stylus, and suspension to push tracking accuracy further. Where the standard 2M Black uses its own cantilever and stylus combination, this cartridge fits a boron cantilever paired with a Nude Shibata diamond and Ortofon's Nano Tube suspension system, three changes that work together rather than separately, since the cantilever's stiffness, the stylus profile, and the suspension's damping all affect how accurately the generator translates groove movement into an electrical signal.

Will it fit your tonearm without modification?

Mounting the 2MR Black LVB 250 is straightforward on tonearms built around a low-form-factor headshell, such as those found on Rega turntables. Its housing is narrow by design, so it integrates without spacers or modifications underneath the tonearm, and the cartridge attaches with just two screws. This makes it a fitting choice for owners of compact, low-profile arms who'd otherwise need adapter plates or shims to mount a standard-bodied cartridge.

What do the boron cantilever and Nude Shibata diamond do?

The cantilever on the 2MR Black LVB 250 is made from boron, a material that's stiff relative to its weight, which lets it transmit groove vibration to the generator with less flex and less time lag than a heavier or more flexible cantilever would. The Nude Shibata diamond mounted on it has a slim, highly polished profile that gives it a wide contact area against the groove walls, and tip dimensions of 6/50 µm reflect that elongated shape. A wider contact patch lets the stylus pick up detail across the audio spectrum, including the upper frequencies where shorter wavelengths are cut closer to the groove wall, supporting the cartridge's stated response of 20 Hz to 20 kHz, +2/-1 dB and a tracking ability of 80 µm at 315 Hz.

How does the Nano Tube suspension change damping?

Suspension on the 2MR Black LVB 250 uses a rubber compound built around Multi Wall Carbon Nano Tubes, referred to as the Nano Tube system. Adding this nano filler to the rubber changes its mechanical properties so the suspension damps cantilever movement more effectively, which keeps the stylus assembly settled as it tracks fast or high-amplitude groove modulation. This sits alongside a dynamic lateral compliance of 22 µm/mN, the figure that describes how readily the suspension yields under the recommended tracking force of 1.6 g, set within a working range of 1.5 to 1.7 g.

What electrical specification should match your phono stage?

Output from the 2MR Black LVB 250 is rated at 5 mV at 1 kHz and 5 cm/sec, generated through a quad-coil system with split pole pins and silver-plated OFC coil wire. That coil arrangement supports a channel separation figure above 27 dB at 1 kHz and channel balance within 1 dB, both of which depend on how evenly the four coils are wound and positioned around the pole pins. Internal impedance sits at 1.2 kOhm with an internal inductance of 630 mH, and Ortofon recommends a load resistance of 47 kOhm with a matching capacitance figure, values your phono stage's input loading should be set to or close to for accurate frequency response.

What's the replacement stylus when it eventually wears?

Wear on the diamond tip is handled by fitting the Stylus 2M Black LVB 250, the matched replacement stylus for this cartridge. Because the stylus assembly is replaceable on its own, owners don't need to buy a new cartridge body, generator, or coil system once the diamond reaches the end of its service life; only the stylus unit, with its boron cantilever and Nude Shibata tip, gets exchanged. At 6 g, the cartridge's weight is also worth checking against your tonearm's effective mass and counterweight range before fitting, since cartridge mass affects how the arm-cartridge system resonates with the suspension.
