Synthesis NYC 175i Valve Integrated Amplifier
The Synthesis NYC 175i Valve Integrated Amplifier combines high-quality valve amplification with modern design. It offers a warm, detailed sound signature, ideal for audiophiles seeking an authentic analogue experience. Featuring 75 watts per channel, it supports a wide range of speakers, ensuring flexibility in various audio setups. Its premium components, including hand-wired circuits and EL34 valves, contribute to its robust performance and durability. With both analogue and digital inputs, it easily integrates into diverse audio systems, offering versatility for users who enjoy both vinyl records and digital streaming sources. The sleek design complements modern home interiors.
Specifications
Synthesis NYC 175i Valve Integrated Amplifier
| Specification | Value |
|---|---|
| Power stage (1 ch.) |
4 X KT88 |
| Input stage (1 ch.) |
1 X 12AX7/ECC83 |
| Driver stage (1 ch.) |
1 X 12BH7 |
| Input impedance |
50 KOhm |
| Input sensitivity |
400mV RMS |
| Output tap |
4/8 Ohm bi-wiring connection |
| Configuration |
Push-Pull Ultra linear 20% tap |
| Power output (1 ch., thd < 1%) |
180W RMS @ 4/8 Ohm |
| Frequency response |
from 20Hz to 20KHz ± 0.5dB |
| Distortion |
1% @ 1KHz (Max Power) |
| S/n ratio |
>90dB “A” weighted |
| Inputs |
Line unbalanced: 4 (RCA) Line balanced: 1 (XLR) |
| Outputs |
Pre out (variable level) |
| Bias setting |
Manual adjustment by LED indicator, Independent for each power tube |
| Dimensions (w,d,h) |
470x620x260mm |
| Weight |
60Kg |
| Line power |
117, 230, 245 Vac 50/60 Hz (see rear label) |
| Fuse |
See rear label |
| Power consumption |
750W Max |
| Remote control |
Body: Anodized black aluminium Transmission type: Infrared Protocol: RC5 Functions: Volume, mute Batteries: 2 x CR2032 Weight: 200g |
Synthesis NYC 175i Valve Integrated Amplifier
Sale price$32,000.00 AUD
