Alphason HR-200S Reference Tonearm Titanium

HR-200S Tonearm Sets New Standard in Vinyl Sound Reproduction

The Alphason HR-200S Reference Tonearm is the pinnacle of audio precision, setting new standards for vinyl sound reproduction. As the latest model in the acclaimed Alphason HR series, the HR-200S elevates playback clarity, depth, and tonal accuracy, redefining what audiophiles can expect from a premium tonearm. Its meticulously crafted design, featuring an advanced titanium arm tube and composite head shell, allows it to deliver a neutral tonal balance, making it sound as if the musicians are right in the room.

Premium Construction for Unrivalled Tonal Clarity

Crafted with a one-piece titanium composite head shell and arm tube, the HR-200S achieves tonal purity that transforms the listening experience. This seamless construction optimises frequency response, dampens unwanted resonances, and brings out the natural texture and presence of each instrument. Built four times more rigid than the HR-100S model, the HR-200S’s advanced composite materials absorb over 90% of vibration energy, providing a stable platform for any cartridge to perform at its peak.

The internal damping system within the tonearm further refines audio purity, eliminating unwanted colouration and maintaining a crystal-clear sound stage. Instruments appear distinct and full of life, creating an immersive listening experience that has been widely praised by critics.

Bespoke Ceramic Bearings with Zero Clearance for Superior Sound Staging

Engineered with ultra-rigid, bespoke ceramic bearings with zero clearance, the HR-200S sets an industry benchmark in bearing precision. These bearings are designed to be up to 20,000 times more rigid than typical tonearm bearings, ensuring unparalleled stability and accuracy in sound reproduction. This rigidity allows for exceptional timing, focus, and coherence across all frequencies, with a pristine, wide sound stage that preserves the energy and dynamics of live performances.

The ceramic bearings also maintain excellent time alignment, providing high definition and a pure, uncoloured audio experience across complex musical arrangements.

Advanced OCC Wiring and Unique Alphason Pin-Jack for Optimal Signal Fidelity

With high-purity, single-crystal OCC (Ohno Continuous Casting) wiring, the HR-200S minimizes capacitance and inductance, ensuring a direct and uninterrupted signal path from the cartridge to the external connector. This advanced wiring system achieves remarkable transparency and eliminates background noise, enhancing dynamic range and producing a "black" backdrop that audiophiles crave for true-to-life audio realism. The Alphason Pin-Jack connector further optimises signal transfer, maintaining the tonal integrity of each recording.

Precise Technical Specifications for Different Models

The HR-200S Reference Tonearm comes in three size variations, offering flexibility to match turntable setups and specific audio preferences:

• HR-200S (9"): Effective length of 229mm, pivot-to-spindle distance of 210.346mm, and an angular offset of 24.083° with an effective mass of 10.2g.
• HR-200S-10.5: Effective length of 266.7mm, pivot-to-spindle distance of 250.865mm, and an angular offset of 20.510° with an effective mass of 11.7g.
• HR-200S-12: Effective length of 305mm, pivot-to-spindle distance of 291.255mm, and an angular offset of 17.841° with an effective mass of 12.1g.

Each variant is meticulously hand-assembled, offering the same uncompromising quality and performance standards regardless of size. The HR-200S design combines engineering mastery with practical adaptability, providing tonal clarity and dynamic performance that satisfies even the most demanding vinyl enthusiasts.

Engineered for Audiophiles: A True Reference Tonearm

The Alphason HR-200S Reference Tonearm isn’t just a component; it’s a transformative addition for serious vinyl collectors and audiophiles. Its cutting-edge materials and precision engineering capture every detail of your records, creating a pure, unblemished playback experience.
